Roller brake tester, enables simulation of braking of the car on actual road conditions and captures data on various parameters which impact braking including brake force, ovality and imbalance between wheels on same axle
| Description | Specificaiton |
|---|---|
| Track Width | 755-2,240 mm Variable |
| Max. Axle Weight | 4,000 kg |
| Rollers Size | 723 x 206 mm |
| Roller Separation | 400 mm |
| Test Speed | 5.4 km/h |
| Motor | 4.6 kW |
| Friction Coefficient Dry | > 0.8 |
| Humid | > 0.6 |
| Measurement Range | 0-6 kN Auto-scale |
| Power Supply | 3 ph, 400 V, 50 Hz |
| Dimension (LxWxH) | (1,430 x 680 x 280 mm) x 2 |
| Weight | 550 kg |
